Technical Specifications

Outputs

• Programmable Analog Outputs: 2
• Frequency Programmable Digital Outputs: 2
• Relay Outputs: 3 relay outputs (high/low point trigger, 3A/250VAC) for intervention thresholds, wash and remote alarm

Inputs

• Hardness: Digital type sensor with 4 wires

Mounting

• Installation: Wall mount / Panel mount

Measurement Range

• Supported Units: mg/L, ppm, ppb, NTU, Percent, pH, mV, mA, µS/cm, mS/cm, PSU, etc.

Power Supply

• Input Voltage: 100–240VAC, 50/60Hz
• Consumption: 5W

Temperature Measurement

• Sensor Type: NTC10K or PT1000

Communication Interface

• Device diagnostics includes basic device and process diagnostics.
• Two-way digital communication for calibration, configuration, and diagnostics.
• Protocol Support: RS485 Modbus

Temperature

• Operating Range: 0 to 50°C

Enclosure

• Protection Rating: IP65 for wall mount, or front facia IP65 for panel mount

Calibration

• Calibration Type: Dual point sensor calibration

Cable Connections

• Polyurethane Glands: 2 Nos

Dimensions

• Overall Dimensions (L × W × H): 144 × 144 × 115 mm
• Cut-out Dimensions: 138 × 138 mm
